24V
CE
16 - 21A
3501 - 4500GPH
Deyuan Brand
Electric
CE/ISO9001:2008
CLH , CLZ, CLN , CSL ,CLV, etc
two year
High Pressure
Cast iron ,Stainless steel, Alloy steel etc
Centrifugal Pump
CCS ABS BV GL
Standard export plywood case
CWL Marine Horizontal Vortex Pump with CE approval
CWL series marine horizontal centrifugal pump are applicable to fire control,cooling and sanitation and applied to
industries,to city water supply and drain,and also to angricultural and orchard irrigation.
The pump rotates anticlockwise viewed from motor.
CWL Vortex Pump
Type | (50HZ,3phase,380v) main technical parameter | Power (kw) | ||||
Capacity (m3/h) | Head (m) | Speed R/min | NPSHR (m) | Shaft power(kw) | ||
32 CWL-4 | 2 | 20.2 | 2900 | 4.2 |
| 1.1 |
4 | 21 | 4.1 | 0.74 | |||
4.8 | 20.9 | 4.1 |
| |||
32CWL-3 | 2 | 31 | 2900 | 3.0 |
| 1.5 |
4 | 30 | 2.5 | 0.99 | |||
4.8 | 29.2 | 2.8 |
| |||
40CWL-5 | 4 | 22.2 | 2900 | 4.4 |
| 1.1 |
8 | 21 | 3.0 | 0.85 | |||
9.6 | 20 | 3.1 |
| |||
40CWL-4 | 4 | 32.3 | 2900 | 3.6 |
| 2.2 |
8 | 30 | 2.6 | 1.31 | |||
9.6 | 28.5 | 2.5 |
| |||
40CWL-3 | 4 | 43 | 2900 | 3.0 |
| 3 |
8 | 42 | 2.5 | 2.13 | |||
9.6 | 41 | 2.9 |
| |||
50CWL-6 | 6 | 22.2 | 2900 | 2.8 |
| 1.5 |
12 | 21 | 2.0 | 1.16 |
Zhuhai City Deyuan Import & Export Co., Ltd
Contact: Wenky
E-mail: sales10[at]deyuanmarine[dot]com
Skype: marinesales10
Tel: + 86 - 756 - 6302052
Fax: + 86 - 756 - 8305812
Mobile: +86 - 13798955776
Web: http://www.deyuanmarine.com
