Guangdong, China (Mainland)
DEYUAN MARINE, Deyuan Brand
CWR, CLH , CLZ, CLN , CSL ,CLV, etc
Centrifugal Pump, Centrifugal Pump
Single-stage Pump
Water
Electric, Electric
Standard
Diesel
Low Pressure, High Pressure
CE/ISO9001:2008
two year
Cast iron ,Stainless steel, Alloy steel etc
Exported packing
Standard export plywood case
CWR Series Marine High Flow Hot Water Circulating Pump For Sale
priming swirl pumps are applicable to pumping elear water and light erroding medium.
The pump rotates clockwise viewed from motor.
CWR Series Marine Horizontal Hot Water Circulating Pump
Type | (50HZ,3phase,380v) main technical parameter | Power (kw) | ||||
Capacity (m3/h) | Head (m) | Speed R/min | NPSHR (m) | Shaft power(kw) | ||
32 CWL-4 | 2 | 20.2 | 2900 | 4.2 |
| 1.1 |
4 | 21 | 4.1 | 0.74 | |||
4.8 | 20.9 | 4.1 |
| |||
32CWL-3 | 2 | 31 | 2900 | 3.0 |
| 1.5 |
4 | 30 | 2.5 | 0.99 | |||
4.8 | 29.2 | 2.8 |
| |||
40CWL-5 | 4 | 22.2 | 2900 | 4.4 |
| 1.1 |
8 | 21 | 3.0 | 0.85 | |||
9.6 | 20 | 3.1 |
| |||
40CWL-4 | 4 | 32.3 | 2900 | 3.6 |
| 2.2 |
8 | 30 | 2.6 | 1.31 | |||
9.6 | 28.5 | 2.5 |
| |||
40CWL-3 | 4 | 43 | 2900 | 3.0 |
| 3 |
8 | 42 | 2.5 | 2.13 | |||
9.6 | 41 | 2.9 |
| |||
50CWL-6 | 6 | 22.2 | 2900 | 2.8 |
| 1.5 |
12 | 21 | 2.0 | 1.16 |
