Self Priming Centrifugal Oil Pump
CWX Series Self-Priming Centrifugal Vortex Pump :
1. Features
This pump belongs to self-priming centrifugal oil pump, it's features are simple construction, easy operation, well moving, convenient repairing, high displacement, high efficiency and wide application slope etc.
2.Application
CYZ Series Self-Priming Centrifugal Oil Pump is used to deliver petrol, kerosene, diesel oil, etc. and the medium of temperature with -20°C~ 80°C .it is a kind of load and unload oil pump in boat, and it is fitted in oil bunker, franker and of can be used to driven sea water and fresh water.
3.List of performance parameters
| Series Name | CYZ |
| Product Name | Self-priming Centrifugal Oil Pump |
| Certification | DNV, ABS, BV, CCS, GL, KR, etc |
| Capacity
m3/h | Head
m | Speed
r/min | Ability of self-priming min/5m | Shaft power
kw | Motor power
kw | NPSHr
m | Suction and discharge port mm |
| 3~30 | 12~75 | 2900 | 1.5~3 | 0.6~6.3 | 0.75~7.5 | 3/3.5/4 | 25~65 |
Self Priming Centrifugal Oil Pump
CWX Series Self-Priming Centrifugal Vortex Pump :
1. Features
This pump belongs to self-priming centrifugal oil pump, it's features are simple construction, easy operation, well moving, convenient repairing, high displacement, high efficiency and wide application slope etc.
2.Application
CYZ Series Self-Priming Centrifugal Oil Pump is used to deliver petrol, kerosene, diesel oil, etc. and the medium of temperature with -20°C~ 80°C .it is a kind of load and unload oil pump in boat, and it is fitted in oil bunker, franker and of can be used to driven sea water and fresh water.
3.List of performance parameters
| Series Name | CYZ |
| Product Name | Self-priming Centrifugal Oil Pump |
| Certification | DNV, ABS, BV, CCS, GL, KR, etc |
| Capacity
m3/h | Head
m | Speed
r/min | Ability of self-priming min/5m | Shaft power
kw | Motor power
kw | NPSHr
m | Suction and discharge port mm |
| 3~30 | 12~75 | 2900 | 1.5~3 | 0.6~6.3 | 0.75~7.5 | 3/3.5/4 | 25~65 |
