12V
RoHS, CCS
5 - 10A
1501 - 2000GPH
CWY series
Wooden Case or as Required
CWY Series Portable Marine Diesel Engine Emergency Fire Pump With 25 m3/h
Diesel engine emergency fire pump
1.Fast discharge.
2.Small volume and light weight.
3.Started quickly.
4.Long service life.
5.Competitive price.
CWY marine diesel emergency fire pump
Product standard:CWY-type marine diesel emergency fire pump is developed in accordance with relevant provisions of the
rules and regulations for the Construction of sea-going steal ships-2009,issued by China Classification society (CCS),and the
International Convention on the safety of Life at sea.
Application:It is mainly applied in emergency fire protection for vessels,and additionally,in industrial and mining enterprises,ports
and docks,warehouse or freight yard etc.
Product features: The pump integrates widely acclaimed features such as light weight,small size,flexibility in moving,rapid starting,
rapid discharge,large capacity of fuel tank,anti-corrosion,reliability and ease of maintenance etc.
When the diameter is between 50 to 65,the pump set may be started by manual or electrically started.The diesel engine may be
vertical,single-cylinder,4-stroke and air cooled.
When the diameter is between 80 to 100,the pump set may be started by spring starter or electrically started.The diesel engine
may be verticql,multi-cylinder,4 stroke and water cooled.The outlet may be deployed as required for air cooling.
Portable Sliding vane pump priming | |||||
Type | Capacity (m3/h) | Head(m) | Speed (r/min) | Suction head m | Time of discharge (s) |
65CWY-30 | 25 | 30 | 3600 | 6~7 | ≤35 |
65CWY-40 | 30 | 40 | 3600 | 6~7 | ≤35 |
Type | Diesel engine | Weight kg | Diameter of discharge mm | ||
Type | Power( kg) | ||||
65CWY-30 | KM186F | 5.7 | 98/83 | 65/50 | |
65 CWY-40 | KM186F | 5.7 | 100/85 | 65/50 |
Self-priming pump | |||||||||
Type | Capacity (m3/h) | Head (m) | Speed (r/min) | Suction head (m) | Time (s) | Diesel engine | Suction diameter (mm) | Weight (kg) | |
Type | Power (kw) | ||||||||
50CWY-43 | 25.5 | 43 | 3600 | 6 | ≤150 | KM 186F | 5.7 | 50/50 | 110 |
65CWY-40 | 30 | 40 | 3600 | 6 | ≤150 | KM 186F | 5.7 | 65/65 | 110 |
80CWF-60 | 50 | 60 | 2950 | 5 | ≤150 | CZ380Q | 20.5 | 80/80 | 410 |
100CWY-75 | 72 | 75 | 1500 | 5 | ≤150 | 2135Aca | 31.5 | 100/100 |
|
Zhuhai City Deyuan Import & Export Co., Ltd
Contact: Wenky
E-mail: sales10[at]deyuanmarine[dot]com
Skype: marinesales10
Tel: + 86 - 756 - 6302052
Fax: + 86 - 756 - 8305812
Mobile: +86 - 13798955776
Web: http://www.deyuanmarine.com
