Marine Diesel Emergency Fire Pumps
Marine Diesel Emergency Fire Pumps
1.Fast discharge.
2.Small volume and light weight.
3.Started quickly.
4.Long service life.
5.Competitive price.
CWY marine diesel emergency fire pump
Product standard:CWY-type marine diesel emergency fire pump is developed in accordance with relevant provisions of the rules and regulations for the Construction of sea-going steal ships-2009,issued by China Classification society (CCS),and the International Convention on the safety of Life at sea.
Application:It is mainly applied in emergency fire protection for vessels,and additionally,in industrial and mining enterprises,ports and docks,warehouse or freight yard etc.
Product features: The pump integrates widely acclaimed features such as light weight,small size,flexibility in moving,rapid starting,rapid discharge,large capacity of fuel tank,anti-corrosion,reliability and ease of maintenance etc.
When the diameter is between 50 to 65,the pump set may be started by manual or electrically started.The diesel engine may be vertical,single-cylinder,4-stroke and air cooled.
When the diameter is between 80 to 100,the pump set may be started by spring starter or electrically started.The diesel engine may be verticql,multi-cylinder,4 stroke and water cooled.The outlet may be deployed as required for air cooling.
Portable Sliding vane pump priming | |||||
Type | Capacity (m3/h) | Head(m) | Speed (r/min) | Suction head m | Time of discharge (s) |
65CWY-30 | 25 | 30 | 3600 | 6~7 | ≤35 |
65CWY-40 | 30 | 40 | 3600 | 6~7 | ≤35 |
Type | Diesel engine | Weight kg | Diameter of discharge mm | ||
Type | Power( kg) | ||||
65CWY-30 | KM186F | 5.7 | 98/83 | 65/50 | |
65 CWY-40 | KM186F | 5.7 | 100/85 | 65/50 | |
Self-priming pump | |||||||||
Type | Capacity (m3/h) | Head (m) | Speed (r/min) | Suction head (m) | Time (s) | Diesel engine | Suction diameter (mm) | Weight (kg) | |
Type | Power (kw) | ||||||||
50CWY-43 | 25.5 | 43 | 3600 | 6 | ≤150 | KM 186F | 5.7 | 50/50 | 110 |
65CWY-40 | 30 | 40 | 3600 | 6 | ≤150 | KM 186F | 5.7 | 65/65 | 110 |
80CWF-60 | 50 | 60 | 2950 | 5 | ≤150 | CZ380Q | 20.5 | 80/80 | 410 |
100CWY-75 | 72 | 75 | 1500 | 5 | ≤150 | 2135Aca | 31.5 | 100/100 |
|
