24V
CE
16 - 21A
3501 - 4500GPH
Deyuan Brand
Electric
CE/ISO9001:2008
YQPV
two year
High Pressure
Cast iron ,Stainless steel, Alloy steel etc
Centrifugal Pump
Standard export plywood case
CWY Type marine diesel engine emergency fire water pump
1.Fast discharge.
2.Small volume and light weight.
3.Started quickly.
4.Long service life.
5.Competitive price.
CWY marine diesel emergency fire pump
Product standard:CWY-type marine diesel emergency fire pump is developed in accordance with relevant provisions of the
rules and regulations for the Construction of sea-going steal ships-2009,issued by China Classification society (CCS),and the
International Convention on the safety of Life at sea.
Application:It is mainly applied in emergency fire protection for vessels,and additionally,in industrial and mining enterprises,ports
and docks,warehouse or freight yard etc.
Product features: The pump integrates widely acclaimed features such as light weight,small size,flexibility in moving,rapid starting,
rapid discharge,large capacity of fuel tank,anti-corrosion,reliability and ease of maintenance etc
Portable Sliding vane pump priming | |||||
Type | Capacity (m3/h) | Head(m) | Speed (r/min) | Suction head m | Time of discharge (s) |
65CWY-30 | 25 | 30 | 3600 | 6~7 | ≤35 |
65CWY-40 | 30 | 40 | 3600 | 6~7 | ≤35 |
Type | Diesel engine | Weight kg | Diameter of discharge mm | ||
Type | Power( kg) | ||||
65CWY-30 | KM186F | 5.7 | 98/83 | 65/50 | |
65 CWY-40 | KM186F | 5.7 | 100/85 | 65/50 | |
Self-priming pump | |||||||||
Type | Capacity (m3/h) | Head (m) | Speed (r/min) | Suction head (m) | Time (s) | Diesel engine | Suction diameter (mm) | Weight (kg) | |
Type | Power (kw) | ||||||||
50CWY-43 | 25.5 | 43 | 3600 | 6 | ≤150 | KM 186F | 5.7 | 50/50 | 110 |
65CWY-40 | 30 | 40 | 3600 | 6 | ≤150 | KM 186F | 5.7 | 65/65 | 110 |
80CWF-60 | 50 | 60 | 2950 | 5 | ≤150 | CZ380Q | 20.5 | 80/80 | 410 |
Zhuhai City Deyuan Import & Export Co., Ltd
Contact: Wenky
E-mail: sales10[at]deyuanmarine[dot]com
Skype: marinesales10
Tel: + 86 - 756 - 6302052
Fax: + 86 - 756 - 8305812
Mobile: +86 - 13798955776
Web: http://www.deyuanmarine.com
