DIN type roller fairlead flexible bollard fairlead roller fairlead stainless steel fairlead

DIN type roller fairlead flexible bollard fairlead roller fairlead stainless steel fairlead



1.Roller Fairlead; Swivel Fairlead;
2.Certificate of GL,DNV,CCS,ABS,BV;
3.Material: Steel;
4.Design by customers' requirement.



Four Roller Fairlead:

1.Roller Fairlead; Fairlead
2.Certificate of GL,DNV,CCS,ABS,BV
3.Material: Steel
4.Design and manufacture according customers' requirements

Rated towing pull	Rope (mm)	Wre size (mm)	A (mm)	B	C	D	E	F	G	weight
20KN	-12	12	180	100	650	80	446	170	10	75kg
30KN	-16	16	230	130	800	100	546	210	10	130kg
50KN	-20	20	250	130	900	120	626	250	15	220kg
80KN	-24	24	280	160	1000	140	716	288	20	320kg
120KN	-32	32	300	160	1200	180	836	366	25	580kg
200KN	-40	40	320	180	1350	245	1030	500	35	1100kg
320KN	-48	40	400	250	1700	300	1236	610	45	2210kg
