KCB Series Gear Oil Pump

Inquire Add to Basket

  • Chongqing, China (Mainland)

  • DEYUAN

  • KCB Series

  • Rotary Pump

  • Gear Pump

  • Oil

  • Electric

  • Standard

  • Diesel

  • Low Pressure

  • Maritime

  • 20M

  • 1 - 4A

  • ISO9001:2000

  • < 500GPH

  • Wooden Case

  • 25-40 days

Specifications


Marine Metering pump
High quality, One-Stop Service, Fast Delivery
Easy Installation and Operatio
ABS, LR, BV, DNV, NK, CCS



Gear oil pump

Electric waste Gear Oil Pump :

We can provide all models of gear Oil Pump, pls inqury us for much info.

Application:
1.It applies to delivering non-corrosive lubricating-lil or equivalent liquid without solid pareicles. 2.Medium temperature bilow 80°C and with the viscosity of 5×10-6~1.5×10-3m2/S(5-1500cSt).




3.It can give performance as transferpump or booster pump in oil delivery system

4. It can be used as fuel pump for delivery,pressurization and injection in fuel supply system .

5. It can be also applied as hydraulic pump supplying hydraulic power in hydraulic system and in all industry fields as lubricating pump.

Main Specification:

Type Capacity Speed Discharge pressure NPSH Motor Power
m3/h L/min r/min Mpa m KW
KCB-18.3 1.1 18.3 1400 1.45 5 1.5
KCB-33.3 2 33.3 1420 1.45 5 2.2
KCB-55 3.3 55 1400 0.33 7 1.5
KCB-83.3 5 83.3 1420 0.33 7 2.2
KCB-135 8 135 940 0.33 5 2.2
KCB-200 12 200 1440 0.33 5 4
KCB-300 18 300 960 0.36 5 5.5
KCB-483.3 29 483.3 1440 0.36 5.5 11
KCB-633 38 633 970 0.28 6 11
KCB-960 58 960 1470 0.28 6.5 18.5
KCB-1200 72 1200 740  0.6  7 37
KCB-1600 95 1600 980

45
KCB-1800 112 1800 740  0.6  7.5 55
KCB-2500 150 2500 985

75
KCB-2850 170 2850 740  0.6  8 90
KCB-3800 230 3800 989

110
KCB-4100 245 4100 743  0.6  8 132
KCB-5400 325 5400 989

160
KCB-5600 330 5600 744  0.6  8 160
KCB-7600 460 7600 989

200
KCB-7000 420 7000 744  0.6  8 185
KCB-9600 570 9600 989

250
