New
1500~20000
China (Mainland)
Deyuan Marine
Marine Separator
Lubricant Oil
220,380,440,460V
11kw
1380*900*1477(mm*mm*mm)
1000Kgs
CCS, ISO
Engineers available to service machinery overseas
2.2~22
Film Wrapping+Wooden Case
60 Days after Payment
Lubricating Oil Separator Unit
Lubricating Oil Separator Unit
Features:
The machine adopts automatic control, it has the advantages of high efficiency, low oil consumption, convenient operation and economic maintenance cost.
The machine is one kind of rotary machine with high speed, after accurate dynamic balancing, it can run for long time with low vibration, safety and security.
Installation Notice:
1.Take into consideration the enough space available to maintenance and repair separator before installation.
2.The foundation must be firm, plan and leveling.
3.All the pipes connecting with separator should be flexible.
4.When installation in ship, the horizontal shaft axes of separator, should parallel with the midship line of the ship, in order to reduce the influence to separator while
Type | Dimension L×W×H | SAE30/40 Lubricating oil(L/H) | Heating Type | Operating Type | Discharging Type |
DYB1207S | 1050*1000*1550 | 800 | Steam | Manual Manipulation | Manual Discharging |
DYB11404S | 1250*900*1600 | 2000 | |||
DYB1103Z | 1250*900*1600 | 800 | Automatic Operation | Automatic Discharging | |
DYB1205Z | 1250*1000*1700 | 1000 | |||
DYB1215Z | 1510*1100*1700 | 1500 | |||
DYB1105Z | 1450*1200*1600 | 2000 | |||
DYB1315Z | 1520*1200*1700 | 2300 | |||
DYB1217Z | 1450*1200*1600 | 3000 | |||
DYB1317Z | 1650*1500*1800 | 4000 | |||
DYB1417Z | 1650*1500*1800 | 5000 |
Zhuhai City Deyuan Import&Export Co.,Ltd
Contact: Laini
Skape: marinesales1
E-mail: sales1[at]deyuanmarine[dot]com
Tel:+86-756-6302052
Fax: +86-756-8305812
Mobile:+86-13672785832
Web: http://deyanmarine.com
