Marine Copper Fixed Rectangular Window

  • China (Mainland)

  • Deyuan Marine

  • various

  • Hinge

  • GB/T5746-2001, ISO3903-1993

  • Brass

  • Toughened Glass

  • 8/10/12/15mm

  • plywood case

  • 10-60days according to the quantity



Marine Copper Fixed Rectangular Window:

Marine Ordinary Rectangular Window Details:

Standard: GB/T5746-2001, ISO3903-1993

Ship’s ordinary rectangular window is used on the supperstructure above freeboard deck or deck house of marine ships and naval ships and in the relative spaces of marine structure. It can be used as rectangular windows of inland ships. This product meets the regulations of SOLAS.



Series:

N

Ordinary

Common rectangular windows with toughened safety glass

P

Fireproof

Rectangular windows used in “B” class fireproof division

H

Heating

Rectangular windows with an electric heated glass



Type:

E-heavy type rectangular window

F-light type rectangular window



Nominal Size Code:

Code

Nominal Size(mm)

1

300x425

2

355x500

3

400x560

4

450x630

5

500x710

6

560x800

7

900x630

8

1000x710

9

1100x800







Main Size List(mm):

Series

Type

Code

Nominal Size

Opening Size

Frame

Opening

wxh

W1xh1

r

W2xh2

W3xh3

N, P, H

E,F

1

300x425

352x477

76

348x473

430x555

ILB,ILW,IRB,IRW,ITB,ITW,OLB,

OLW,ORB,ORW,OTB,OTW,NOB,NOW

2

355x500

407x552

76

403x548

485x630

3

400x560

452x612

76

448x608

530x690

4

450x630

502x682

126

498x678

580x760

5

500x710

552x762

126

548x758

630x840

6

560x800

612x852

126

608x848

690x930

7

900x630

952x682

126

948x678

1030x760

8

1000x710

1052x762

126

1048x758

1130x840

9

1100x800

1152x852

126

1148x848

1230x930
