Marine Electric Fire Water Monitor for Fire Fighting System

Inquire Add to Basket

  • SS Series

  • 140m

  • 589kw

  • DEYUAN MARINE

  • China

  • 1200m3/H.

  • 1800r/Min

  • 80%

  • ABS, GL, DNV, BV, CCS Class

Electric Operated Fire Monitor

1.Effective capacity:   4000L/min.
2.The max pressure:    16bar.
3.Inlet:   Flange DN80 PN16 .
4.Outlet:   Screw thread.
5.Optional inlet flange: DN100 PN16/ ANSI3''



China Deyuan Marine Fitting Co.,ltd is leading supplier of FIFI system,Fire fighting system,
marine fire pump,foam fire monitor,fire monitor,electric fire monitor,CO2 Fire-extinguishing system,
fire extinguishing system,Pls contact us for more specific details.

Descriptions:    Produced on requirement
Effective capacity:   4000L/min
The max pressure:    16bar
Inlet:   Flange DN80 PN16
Outlet:   Screw thread
Optional inlet flange: DN100 PN16/ ANSI3''
Rotation range:
Horizontal:  340°
Vertical:   +85°~ -75°
Weight:  ~75Kg
Materials:
Body:  Stainless Steel/Carbon Steel/Anti-corrosion aluminum alloy
Sealing:  NBR
Pipe:   Hard aluminum alloy
Flange:  Stainless Steel/Carbon Steel/Anti-corrosion aluminum alloy
Painting:   Red RAL3000
The monitor can be arrested in any horizontal or vertical position


Marine Electric Fire Water Monitor for Fire Fighting System
Marine Electric Fire Water Monitor for Fire Fighting System
Marine Electric Fire Water Monitor for Fire Fighting System
