Marine Fireproof Side Scuttle/Porthole

  • China (Mainland)

  • Deyuan Marine

  • various

  • Hinge

  • GB/T14413-93

  • Brass

  • Toughened Glass

  • A0,A60

  • plywood case

  • 10-60days according to the quantity



Marine Fireproof Side Scuttle/Porthole:

Standard: IMO Res MSC 61(67), IMO Res. A.754(18)

It is suitable for accommodations & other marine instructments with A60 fireproof requirement, and with EC type approval certificate.



Main Material:

Frame: Steel

Glass: Fireproof Glass



Main Size List(mm):

Nominal Size oOpening Size Outside Size D2 Main Glass Thickness t Glass Size
D D1 D2 Heavy Medium D3
D200 D383 D380 10 8 D240
D250 D433 D430 12 8 D290
D300 D483 D3480 15 10 D340
D350 D533 D530 15 12 D390
D400 D583 D580 15 12 D440
D450 D633 D630 19 15 D490
