Guangdong, China (Mainland)
DEYUAN MARINE, Deyuan Brand
GF, CLH , CLZ, CLN , CSL ,CLV, etc
Centrifugal Pump, Centrifugal Pump
Single-stage Pump
Water
Electric, Electric
Standard
Electricity
Low Pressure
Water
CE/ISO9001:2008
two year
24V
16 - 21A
3501 - 4500GPH
Standard export plywood case
Normally 10days after receive the payment
Marine GF Automatic Hot Water Pump
1.Fast discharge.
2.Small volume and light weight.
3.Started quickly.
4.Long service life.
5.Competitive price.
GF Automatic Hot Water Pump
priming swirl pumps are applicable to pumping elear water and light erroding medium.
The pump rotates clockwise viewed from motor.
Type | (50HZ,3phase,380v) main technical parameter | Power (kw) | ||||
Capacity (m3/h) | Head (m) | Speed R/min | NPSHR (m) | Shaft power(kw) | ||
32 CWL-4 | 2 | 20.2 | 2900 | 4.2 |
| 1.1 |
4 | 21 | 4.1 | 0.74 | |||
4.8 | 20.9 | 4.1 |
| |||
32CWL-3 | 2 | 31 | 2900 | 3.0 |
| 1.5 |
4 | 30 | 2.5 | 0.99 | |||
4.8 | 29.2 | 2.8 |
| |||
40CWL-5 | 4 | 22.2 | 2900 | 4.4 |
| 1.1 |
8 | 21 | 3.0 | 0.85 | |||
9.6 | 20 | 3.1 |
| |||
40CWL-4 | 4 | 32.3 | 2900 | 3.6 |
| 2.2 |
8 | 30 | 2.6 | 1.31 | |||
9.6 | 28.5 | 2.5 |
| |||
40CWL-3 | 4 | 43 | 2900 | 3.0 |
| 3 |
8 | 42 | 2.5 | 2.13 | |||
9.6 | 41 | 2.9 |
| |||
50CWL-6 | 6 | 22.2 | 2900 | 2.8 |
| 1.5 |
12 | 21 | 2.0 | 1.16 |
