Marine Horizontal Centrifugal Pump CIS Series
1.High quality.
2.Suitable for fluid drive system.
3.Competitive price.
4.Advanced techniques.
CIS series marine horizontal centrifugal pump
CIS series marine horizontal centrifugal pump is widely used for transfer of fresh water,seawater.The pumps are applicable to fire control,cooling and sanitation and applied to industries,to city water supply and drain,and also to agricultural and orchard irrigation.
The pump rotateds clockwise viewed from motor.
Type | (50HZ,3phase,380v)main techincal parameter | Motor power (kw) | ||||
Capacity (m3/h) | Head (m) | Speed (r/min) | NPSHR (m) | Shaft power(kw) | ||
CIS50-32-125 | 7.5 | 22 | 2900 | 2 |
| 2.2 |
12.5 | 20 | 2 | 1.13 | |||
15 | 18.5 | 2.5 |
| |||
CIS50-32-125A | 6.7 | 17.6 | 2900 | 2 |
| 1.5 |
11.2 | 16 | 2 | 0.82 | |||
13.4 | 14.8 | 2.5 |
| |||
CIS50-32-160 | 7.5 | 34.3 | 2900 | 2 |
| 3 |
12.5 | 32 | 2 | 2.02 | |||
15 | 29.6 | 2.5 |
| |||
CIS50-32-160A | 7.05 | 30.5 | 2900 | 2 |
| 2.2 |
11.8 | 28.5 | 2 | 1.70 | |||
14.1 | 26.3 | 2.5 |
| |||
CIS50-32-160B | 6.48 | 25.6 | 2900 | 2 |
| 1.5 |
10.8 | 23.8 | 2 | 1.35 | |||
13 | 22 | 2.5 |
| |||
CIS50-32-200 | 7.5 | 52.5 | 2900 | 2 |
| 5.5 |
12.5 | 50 | 2 | 3.54 | |||
15 | 48 | 2.5 |
| |||
CIS50-32-200A | 7.2 | 48.3 | 2900 | 2 |
| 4 |
12 | 46 | 2 | 3.1 | |||
14.4 | 44.2 | 2.5 |
| |||
CIS50-32-200B | 6.5 | 39.1 | 2900 | 2 |
| 3 |
10.8 | 37.3 | 2 | 2.29 | |||
12.9 | 35.8 | 2.5 |
| |||
CIS50-32-250 | 7.5 | 82 | 2950 | 2 |
| 11 |
12.5 | 80 | 2 | 7.17 | |||
15 | 78.5 | 2.5 |
| |||
CIS50-32-250A | 7 | 71.8 | 2900 | 2 |
| 7.5 |
11.7 | 70 | 2 | 5.87 | |||
14 | 68.7 | 2.5 |
| |||
CIS50-32-250B | 6.5 | 61.2 | 2900 | 2 |
| 5.5 |
10.8 | 59.7 | 2 | 4.63 | |||
13 | 58.5 | 2.5 |
| |||
|
|
|
|
|
|
|
CIS65-50-125 | 15 | 21.8 | 2900 | 2 |
| 3 |
25 | 20 | 2.5 | 1.97 | |||
30 | 18.5 | 3 |
| |||
CIS65-50-125A | 14.2 | 19.7 | 2900 | 2 |
| 2.2 |
23.8 | 18.1 | 2.5 | 1.7 | |||
28.5 | 16.7 | 3 |
| |||
CIS65-50-160 | 15 | 35 | 2900 | 2 |
| 5.5 |
25 | 32 | 2 | 3.35 | |||
30 | 30 | 2.5 |
| |||
CIS65-50-160A | 14 | 30.5 | 2900 | 2 |
| 4 |
23.4 | 28 | 2 | 2.75 | |||
28 | 26.2 | 2.5 |
| |||
CIS65-50-160B | 13 | 26.3 | 2900 | 2 |
| 3 |
21.7 | 24 | 2 | 2.2 | |||
26 | 22.6 | 2.5 |
| |||
CIS65-40-200 | 15 | 53 | 2900 | 2 |
| 7.5 |
25 | 50 | 2 | 5.67 | |||
30 | 47 | 2.5 |
| |||
CIS65-40-200A | 14 | 46 | 2900 | 2 |
| 5.5 |
23.4 | 44 | 2 | 4.67 | |||
28 | 41 | 2.5 |
|
Zhuhai City Deyuan Import & Export Co., Ltd
Contact: Gary
E-mail: sales9[at]deyuanmarine[dot]com
Skype: marinesales9
Tel: + 86 - 756 - 6302052
Fax: + 86 - 756 - 8305812
Mobile: +86 - 1379895750
Web: http://www.deyuanmarine.com
