Marine Offshore Moorfast Anchor

Marine Offshore Moorfast Anchor

1.Moorfast Anchor; Mooring and Offshore Anchor.
2.Weight: 1000-70000Kg.
3.Certificate:CCS,DNV,GL,BV,ABS.
4.Material:Steel.

Marine Offshore Moorfast Anchor

1.Moorfast Anchor; Mooring and Offshore Anchor
2.Weight: 1000-70000Kg
3.Certificate:CCS,DNV,GL,BV,ABS
4.Material:Steel

MOORFAST ANCHOR
Anchor Weight(kg)	A	B	C	D	E	Proof Test(kN)
1000	61	75	37	25	19	30000
3000	88	109	54	37	27	72500
6000	101	143	61	42	31	121300
8000	122	153	75	51	38	145000
10000	131	157	80	55	41	165600
12000	139	167	85	58	43	184700
14000	147	177	90	61	45	205000
16000	153	187	94	64	48	222700
20000	164	196	102	69	51	249400
30000	189	217	118	79	59	319400
40000	215	248	127	86	63	386000
50000	222	257	132	89	66	448300
