Steel
LR
> 11000kg
Type M Spek Anchor
Packaging: Export standard
30 days
Type M Spek Anchor
1.Model: Type M spek anchor.
2.certificates:ABS,CCS, GL, LR, BV and DNV.
3.Weight:2460-11100KG.
4.Material:steel.
Type M spek anchor
1.Model: Type M spek anchor
2.Certificates:ABS,CCS, GL, LR, BV and DNV
3.Weight:2460-11100KG
4.Material:steel
Nominal weight (KG) | mm | ||||
| A | B | C | D | F |
|
|
|
|
|
|
2460 | 2010 | 1100 | 324 | 1514 | 764 |
2640 | 2070 | 1150 | 352 | 1584 | 794 |
2850 | 2070 | 1150 | 352 | 1584 | 804 |
3060 | 2155 | 1200 | 360 | 1650 | 802 |
3300 | 2155 | 1200 | 360 | 1650 | 834 |
3540 | 2350 | 1200 | 360 | 1650 | 834 |
3780 | 2400 | 1350 | 393 | 1850 | 880 |
|
|
