Marine Vertical Centrifugal Sea Water Pump For Sale
Marine Vertical Centrifugal Sea Water Pump (CLH series)
1.Able to carry sea water under 80degrees.
2.Service as marine bilge pump,marine ballast pump,marine fire pump etc.
3.Compact design.
CLH series marine pumps are used at cabin bottom to cool water and fight fire.It is able to carry sea water under 80degrees.
Fresh water and other non-eroding liquid.
CLH series marine vertical centrifugal pump
Type | Main technical parameter (50hz,3phase,380v) | Motor power | ||||
Capacity (m3/h) | Head (m) | Speed R/min | NPSHR m | Shaft power kw | ||
25CLH-6.5Z | 3 | 8 | 2900 | 4 | 0.16 | 0.75 |
40CLH-5Z | 10 | 30 | 2900 | 4 | 1.82 | 2.2 |
40CLH-3.5Z | 5 | 30 | 2900 | 4 | 1.26 | 1.5 |
40CLH-3Z | 10 | 50 | 2900 | 2.8 | 3.24 | 4 |
40CLH-2.5Z | 10 | 65 | 2900 | 3 | 4.66 | 5.5 |
40CLH-2Z | 5 | 50 | 2900 | 2.8 | 2.28 | 3 |
50CLH-7Z | 20 | 30 | 2900 | 3 | 2.47 | 4 |
50CLH-7AZ | 18 | 25 | 2900 | 3 | 1.92 | 3 |
50CLH-5Z | 20 | 45 | 2900 | 4 | 4.1 | 5.5 |
50CLH-4.5Z | 20 | 50 | 2900 | 3 | 4.54 | 5.5 |
50CLH-3.5Z | 20 | 65 | 2900 | 3.5 | 8.85 | 11 |
65CLH-8.5Z | 30 | 30 | 2900 | 3 | 4.02 | 5.5 |
65CLH-8.5AZ | 25 | 26 | 2900 | 3 | 2.95 | 4 |
65CLH-5.5Z | 30 | 50 | 2950 | 3 | 6.92 | 11 |
65CLH-5.5AZ | 27 | 45 | 2900 | 3 | 5.7 | 7.5 |
65CLH-4.5Z | 30 | 65 | 2950 | 3 | 9.48 | 11 |
65CLH-4.5AZ | 27 | 58 | 2950 | 3 | 7.9 | 11 |
65CLH-3Z | 25 | 86 | 2950 | 4 | 14.9 | 18.5 |
Zhuhai City Deyuan Import & Export Co., Ltd
Contact: Wenky
E-mail: sales10[at]deyuanmarine[dot]com
Skype: marinesales10
Tel: + 86 - 756 - 6302052
Fax: + 86 - 756 - 8305812
Mobile: +86 - 13798955776
Web: http://www.deyuanmarine.com
