24V
CE
16 - 21A
3501 - 4500GPH
Deyuan Brand
Electric
CE/ISO9001:2008
CLH , CLZ, CLN , CSL ,CLV, etc
two year
High Pressure
Cast iron ,Stainless steel, Alloy steel etc
Centrifugal Pump
WOODEN CASE
Normally 30days after receive the payment
Marine Vertical Deep-Well Oil Pump
priming swirl pumps are applicable to pumping elear water and light erroding medium.
The pump rotates clockwise viewed from motor.
marine vertical deep-well oil pump
Type | (50HZ,3phase,380v) main technical parameter | Power (kw) | ||||
Capacity (m3/h) | Head (m) | Speed R/min | NPSHR (m) | Shaft power(kw) | ||
32 CWL-4 | 2 | 20.2 | 2900 | 4.2 |
| 1.1 |
4 | 21 | 4.1 | 0.74 | |||
4.8 | 20.9 | 4.1 |
| |||
32CWL-3 | 2 | 31 | 2900 | 3.0 |
| 1.5 |
4 | 30 | 2.5 | 0.99 | |||
4.8 | 29.2 | 2.8 |
| |||
40CWL-5 | 4 | 22.2 | 2900 | 4.4 |
| 1.1 |
8 | 21 | 3.0 | 0.85 | |||
9.6 | 20 | 3.1 |
| |||
40CWL-4 | 4 | 32.3 | 2900 | 3.6 |
| 2.2 |
8 | 30 | 2.6 | 1.31 | |||
9.6 | 28.5 | 2.5 |
| |||
40CWL-3 | 4 | 43 | 2900 | 3.0 |
| 3 |
8 | 42 | 2.5 | 2.13 | |||
9.6 | 41 | 2.9 |
| |||
50CWL-6 | 6 | 22.2 | 2900 | 2.8 |
| 1.5 |
12 | 21 | 2.0 | 1.16 | |||
