Vortex Pump
Marine Vortex Pump W(Z) Series
*Small flow, high head.
*Self-priming vortex impeller.
*GB/T5656-2008, DIN24256
1W(Z) series marine vortex pump
1W(Z),W series marine self-priming swirl pumps are applicable to pumping clear water and light eroding medium.
The pump rotates clockwise viewed from motor.
Type | 50HZ,3phase,380V main techinical parameter | Motor power (kw) | Remarks | ||||
Capacity (m3/h) | Head (m) | Speed (r/min) | NPSHR (m) | Shaft power (kw) | |||
1W-3 | 3 | 10 | 1450 | 6 | 0.42 | 0.75 | No exhaust |
1WZ-3 | 3 | 10 | 1450 | 6 | 0.42 | 0.75 | Self-priming |
1W-0.9 | 1.8 | 25.5 | 1450 | 3.5 | 0.625 | 1.5 | No exhaust |
1WZ-0.9 | 1.8 | 25.5 | 1450 | 3.5 | 0.625 | 1.5 | Self-priming |
