China (Mainland)
Deyuan Marine
various
Hinge
CB/T3226-1995
Aluminum
Toughened Glass
8/10/12/15mm
plywood case
10-60days according to the quantity
Marine Wheel House Aluminum Fixed Rectangular Window
Standard: CB/T3226-1995
It is installed in the wheel houses, bridges, enclosed spaces which is used for observation and operation of various types of ships and marine structures.
The shape can be rectangular, parallelogram or trapezoidal .
Type | Window frame type | Name | Material of window frame |
A | BH | Bolted fixed rectangular window with an electric heated glass pane | Aluminum Alloy |
BN | Bolted fixed rectangular window with a toughened glass pane | ||
B | WH | Welded fixed rectangular window with an electric heated glass pane | Carbon Steel |
WN | Welded fixed rectangular window with a toughened glass pane |
Type | Nominal Size | Frame | Size of opening | Glass Thickness | Weight (kgs) | ||||
WXH | W1XH1 | W2XH2 | W3XH3 | r | BH | BN | BH | BN | |
A | 800X630 | 848X678 | 930X760 | 852x682 | 126 | 12 | 15 | 25.5 | 25.9 |
800X710 | 848X758 | 930X840 | 852x762 | 12 | 15 | 28.1 | 28.7 | ||
900X630 | 948X678 | 1030X760 | 952x682 | 12 | 17 | 28.2 | 30.0 | ||
900X710 | 948X758 | 1030X840 | 952x762 | 12 | 17 | 30.9 | 32.9 | ||
900X800 | 948X848 | 1030X930 | 952x852 | 12 | 17 | 33.9 | 36.1 | ||
1200X630 | 1248X378 | 1330X760 | 1252x682 | 15 | 20 | 41.6 | 44.0 | ||
1200X710 | 1248X758 | 1330X840 | 1252x762 | 15 | 20 | 45.9 | 48.6 | ||
1200X800 | 1248X848 | 1330X930 | 1252x852 | 15 | 20 | 50.6 | 53.6 | ||
1500X710 | 1548X758 | 1630X840 | 1552x762 | 15 | 20 | 56.1 | 59.4 | ||
1500X800 | 1548X848 | 1630X930 | 1552x852 | 15 | 20 | 61.2 | 64.9 | ||
1800X710 | 1848X758 | 1930X840 | 1852x762 | 15 | 20 | 66.3 | 70.3 | ||
1800X800 | 1848X848 | 1930X930 | 1852x852 | 15 | 20 | 72.4 | 76.8 | ||
1800X900 | 1848X948 | 1930X1030 | 1852x952 | 15 | 20 | 77.5 | 82.5 | ||
Type | Nominal Size | Frame | Size of opening | Glass Thickness | Weight (kgs) | ||||
WXH | W1XH1 | W2XH2 | W3XH3 | r | WH | WN | WH | WN | |
B | 800X630 | 848X678 | 930X760 | 852x682 | 126 | 12 | 15 | 41.3 | 41.8 |
800X710 | 848X758 | 930X840 | 852x762 | 12 | 15 | 44.2 | 44.8 | ||
900X630 | 948X678 | 1030X760 | 952x682 | 12 | 17 | 45.1 | 46.9 | ||
900X710 | 948X758 | 1030X840 | 952x762 | 12 | 17 | 48.5 | 50.5 | ||
900X800 | 948X848 | 1030X930 | 952x852 | 12 | 17 | 52.4 | 54.6 | ||
1200X630 | 1248X378 | 1330X760 | 1252x682 | 15 | 20 | 60.9 | 63.3 | ||
1200X710 | 1248X758 | 1330X840 | 1252x762 | 15 | 20 | 66.6 | 69.2 | ||
1200X800 | 1248X848 | 1330X930 | 1252x852 | 15 | 20 | 72.2 | 75.2 | ||
1500X710 | 1548X758 | 1630X840 | 1552x762 | 15 | 20 | 79.8 | 83.1 | ||
1500X800 | 1548X848 | 1630X930 | 1552x852 | 15 | 20 | 86.4 | 90.1 | ||
1800X710 | 1848X758 | 1930X840 | 1852x762 | 15 | 20 | 93.1 | 97.1 | ||
1800X800 | 1848X848 | 1930X930 | 1852x852 | 15 | 20 | 100.4 | 104.8 | ||
1800X900 | 1848X948 | 1930X1030 | 1852x952 | 15 | 20 | 108.6 | 113.6 |
*The size is in the list is just for reference, it is can be customerized according to the actual situation of the vessel.
Electrical Supply | Overheating protection device | Minimum power loading w/dw2 | ||||
Current | Voltage (V) | Frequency (HZ) | 7 | 12 | 17 | |
Code | ||||||
DC | 24 | - | G | 7G01 | 12G01 | 17G01 |
S | 7S01 | 12S01 | 17S01 | |||
110 | - | G | 7G02 | 12G02 | 17G02 | |
S | 7S02 | 12S02 | 17S02 | |||
220 | - | G | 7G03 | 12G03 | 17G03 | |
S | 7S03 | 12S03 | 17S03 | |||
G---group regulator, S---single regulator |
Package: Plywood Case
Shipping: by air or by sea
One-Stop Service: We supply all kinds of marine and offshore products, from securing the order to final delivery, we work hard to make sure everything goes as required and with high standard quality.
High quality: We are here to provide you with safe and reliable goods. Quality is always our main priority, our quality control program make sure that no defect or poor workmanship will be supplied. According to customer's requirement, our quality can meet the rules and standards of International Class Society such as LR, ABS, DNV, GL, BV, NK, KR, RINA, IRS and CCS.
Professional: With more than 7 years of experience in marine and offshore field, our marketing and technical team can assure you that we can understand your requirement well and deal with your inquiry professionally.
Fast Delivery: We cooperate with the reliable logistic partner, including land, air and sea to help us deliver the goods to your hand on time.
Reliable Partner: With 95% clients' satisfactory, we are confident to be your reliable partner.
We supply all kinds of marine and offshore products for various vessels including VLCC, FSO, FPSO, LNGC, LPGC, Container Ships, Cargo Liners, Bulk Carriers, Oil Tankers and oil platform, from securing the order to final delivery, we work hard to make sure everything goes as required and with high standard quality.
1. When inquiry, the size is necessary.
2.All inquiry will be replied within 24 hours.
Marine Wheel House Aluminum Fixed Rectangular Window
Standard: CB/T3226-1995
It is installed in the wheel houses, bridges, enclosed spaces which is used for observation and operation of various types of ships and marine structures.
The shape can be rectangular, parallelogram or trapezoidal .
Type | Window frame type | Name | Material of window frame |
A | BH | Bolted fixed rectangular window with an electric heated glass pane | Aluminum Alloy |
BN | Bolted fixed rectangular window with a toughened glass pane | ||
B | WH | Welded fixed rectangular window with an electric heated glass pane | Carbon Steel |
WN | Welded fixed rectangular window with a toughened glass pane |
Type | Nominal Size | Frame | Size of opening | Glass Thickness | Weight (kgs) | ||||
WXH | W1XH1 | W2XH2 | W3XH3 | r | BH | BN | BH | BN | |
A | 800X630 | 848X678 | 930X760 | 852x682 | 126 | 12 | 15 | 25.5 | 25.9 |
800X710 | 848X758 | 930X840 | 852x762 | 12 | 15 | 28.1 | 28.7 | ||
900X630 | 948X678 | 1030X760 | 952x682 | 12 | 17 | 28.2 | 30.0 | ||
900X710 | 948X758 | 1030X840 | 952x762 | 12 | 17 | 30.9 | 32.9 | ||
900X800 | 948X848 | 1030X930 | 952x852 | 12 | 17 | 33.9 | 36.1 | ||
1200X630 | 1248X378 | 1330X760 | 1252x682 | 15 | 20 | 41.6 | 44.0 | ||
1200X710 | 1248X758 | 1330X840 | 1252x762 | 15 | 20 | 45.9 | 48.6 | ||
1200X800 | 1248X848 | 1330X930 | 1252x852 | 15 | 20 | 50.6 | 53.6 | ||
1500X710 | 1548X758 | 1630X840 | 1552x762 | 15 | 20 | 56.1 | 59.4 | ||
1500X800 | 1548X848 | 1630X930 | 1552x852 | 15 | 20 | 61.2 | 64.9 | ||
1800X710 | 1848X758 | 1930X840 | 1852x762 | 15 | 20 | 66.3 | 70.3 | ||
1800X800 | 1848X848 | 1930X930 | 1852x852 | 15 | 20 | 72.4 | 76.8 | ||
1800X900 | 1848X948 | 1930X1030 | 1852x952 | 15 | 20 | 77.5 | 82.5 | ||
Type | Nominal Size | Frame | Size of opening | Glass Thickness | Weight (kgs) | ||||
WXH | W1XH1 | W2XH2 | W3XH3 | r | WH | WN | WH | WN | |
B | 800X630 | 848X678 | 930X760 | 852x682 | 126 | 12 | 15 | 41.3 | 41.8 |
800X710 | 848X758 | 930X840 | 852x762 | 12 | 15 | 44.2 | 44.8 | ||
900X630 | 948X678 | 1030X760 | 952x682 | 12 | 17 | 45.1 | 46.9 | ||
900X710 | 948X758 | 1030X840 | 952x762 | 12 | 17 | 48.5 | 50.5 | ||
900X800 | 948X848 | 1030X930 | 952x852 | 12 | 17 | 52.4 | 54.6 | ||
1200X630 | 1248X378 | 1330X760 | 1252x682 | 15 | 20 | 60.9 | 63.3 | ||
1200X710 | 1248X758 | 1330X840 | 1252x762 | 15 | 20 | 66.6 | 69.2 | ||
1200X800 | 1248X848 | 1330X930 | 1252x852 | 15 | 20 | 72.2 | 75.2 | ||
1500X710 | 1548X758 | 1630X840 | 1552x762 | 15 | 20 | 79.8 | 83.1 | ||
1500X800 | 1548X848 | 1630X930 | 1552x852 | 15 | 20 | 86.4 | 90.1 | ||
1800X710 | 1848X758 | 1930X840 | 1852x762 | 15 | 20 | 93.1 | 97.1 | ||
1800X800 | 1848X848 | 1930X930 | 1852x852 | 15 | 20 | 100.4 | 104.8 | ||
1800X900 | 1848X948 | 1930X1030 | 1852x952 | 15 | 20 | 108.6 | 113.6 |
*The size is in the list is just for reference, it is can be customerized according to the actual situation of the vessel.
Electrical Supply | Overheating protection device | Minimum power loading w/dw2 | ||||
Current | Voltage (V) | Frequency (HZ) | 7 | 12 | 17 | |
Code | ||||||
DC | 24 | - | G | 7G01 | 12G01 | 17G01 |
S | 7S01 | 12S01 | 17S01 | |||
110 | - | G | 7G02 | 12G02 | 17G02 | |
S | 7S02 | 12S02 | 17S02 | |||
220 | - | G | 7G03 | 12G03 | 17G03 | |
S | 7S03 | 12S03 | 17S03 | |||
G---group regulator, S---single regulator |
Package: Plywood Case
Shipping: by air or by sea
One-Stop Service: We supply all kinds of marine and offshore products, from securing the order to final delivery, we work hard to make sure everything goes as required and with high standard quality.
High quality: We are here to provide you with safe and reliable goods. Quality is always our main priority, our quality control program make sure that no defect or poor workmanship will be supplied. According to customer's requirement, our quality can meet the rules and standards of International Class Society such as LR, ABS, DNV, GL, BV, NK, KR, RINA, IRS and CCS.
Professional: With more than 7 years of experience in marine and offshore field, our marketing and technical team can assure you that we can understand your requirement well and deal with your inquiry professionally.
Fast Delivery: We cooperate with the reliable logistic partner, including land, air and sea to help us deliver the goods to your hand on time.
Reliable Partner: With 95% clients' satisfactory, we are confident to be your reliable partner.
We supply all kinds of marine and offshore products for various vessels including VLCC, FSO, FPSO, LNGC, LPGC, Container Ships, Cargo Liners, Bulk Carriers, Oil Tankers and oil platform, from securing the order to final delivery, we work hard to make sure everything goes as required and with high standard quality.
1. When inquiry, the size is necessary.
2.All inquiry will be replied within 24 hours.
