Marine casting bar type cable stopper
Chain chain stopper consists of a chain hook, a screw and a short telescopic chains. It is fixed with a shackle on deck when using the chain hook on a horizontal chain link, and then tighten the screws stretching that cho taut chain. It is often associated with spiral chain system supporting the use of a spiral chain stopper auxiliary devices.
We supply all kinds of chain stopper .Quality management and product strict according to IACS requirement.
Cast steel chain stopper
Chain Dia. | 12.5~14 | 16~17.5 | 19~20.5 | 22~24 | 26~28 |
B | 142 | 170 | 193 | 219 | 241 |
H | 162 | 190 | 216 | 241 | 270 |
L | 235 | 270 | 310 | 345 | 385 |
fillet | 5 | 6 | 6 | 7 | 7 |
Weight (kg) | 20 | 25 | 30 | 37 | 46 |
