Marine vertical double-stage double-outlet centrifugal water pump
CLN Series marine vertical double-stage double-outlet centrifugal pump is used to deliver fresh water and seawater,widely used for cooling,fire control,chamber loading
and other general water drainage.It can be used as the alkali liquid pump and distilling pump in seawater desalination.It
can also be used for industrial and urban water supply.The temperature of delivery mediem shall not be over 80°C.
Type | (50HZ,3phase,380v)main technical parameter | |||
Capacity (m3/h) | Head (m) | Speed (R/min) | NPSHR (m) | |
CLN80-340/2A | 51/51 | 29.5/65 | 1480 | 2.8 |
CLN80-340-2C | 116/58 | 24/61 | 1480 | 3.4 |
CLN80-340-2D | 112/54 | 15/51.5 | 1480 | 4.3 |
CLN80-340-2E | 141/62 | 25.5/59 | 1480 | 4.2 |
CLN100-380/2A | 95/91 | 36.5/86 | 1480 | 4.1 |
CLN100-380/2C | 149/95 | 27.5/77 | 1480 | 3.7 |
CLN100-380/2D | 141/95 | 16.5/60.5 | 1480 | 3.6 |
CLN100-380/2E | 199/99 | 23.5/69.5 | 1480 | 4.2 |
CLN125-380/2A | 124/120 | 33.5/77 | 1480 | 4.0 |
CLN125-380/2C | 215/120 | 23.5/65 | 1480 | 4.2 |
CLN125-380/2D | 199/108 | 17/60.5 | 1480 | 4.2 |
CLN125-380/2E | 257/124 | 24/68.5 | 1480 | 3.5 |
CLN150-380/2A | 199/182 | 33/79 | 1480 | 5.1 |
CLN150-380/2C | 248/174 | 22/71.5 | 1480 | 4.9 |
CLN150-380/2D | 265/166 | 14.5/62 | 1480 | 4.2 |
CLN150-380/2E | 389/182 | 22/70 | 1480 | 4.6 |
