Square Steel Watertight Hatch Cover

Specifications

Steel Watertight Hatch Cover:
1)Standard or customerized size
2)Comptitive price&good quality
3)Pressure&watertight test

Square Steel  Watertight  Hatch Cover:

Standard:CB/T3842-2000

The hatch cover is with the spring-balance device and the central clip device, so it is watertight, and can be opened or closed quickly and easily.There are two types, A type is round, B type is square. It is used as the quick entry or exit which has the watertight demand on various ships

The use pressure is 0.2Mpa.

Watertight test requirement: The cover must be closed, and maintain 15 minutes after 0.3Mpa water is put into the test tank.





Main Material:

Cover-Steel

Coaming-Steel

Handwheel-Steel, Stainless Steel or Steel with Galv

Spring-Spring Steel





Main Size List(mm):

Clear Size	Cut Out Size	Coaming Inner Diameter	Cover Outside Diameter	Cover Thickness	Coaming		Center Distance	Weight
AXA	A1XA1	A2XA2	A3XA3	t	t1	H	B	kgs
600X600	640X640	670X670	720X720	12	12	200	510	310
700X700	740X740	770X770	820X820				560	340
800X800	840X840	870X870	920X920				610	380























.
