KC-200 27Mh 40 channel AM/FM CB transceiver
Advantages
Phase locked loop circuitry gives precise frequency control and stability over all 40 channels
Ceramic filters give superior selectivity and freedom from adjacent channel interference
Green led channel indicator clearly shows which channel is activated
Red led(TX) and Green Led(RX) show the operative modality: TX=transmission; RX=reception
Hysteresis-type squelch circuit automatically compensates for signal fading to eliminate signal chopping during message reception
With 40 channels AM/40 channels FM
Power level Max 4 Watt with Poland/EU band
Emergency switch lets you switch to channel 9 or 19 instantly
Jacks for external speaker let you hook up other speaker systems
Works with negative ground 12-13.8v DC.
With the LED display
Specifications
For receiver
Frequency coverage: 26.965 to 27.405 MHz(EU band), 26.960 to 27.400 Mhz(Poland)
Sensitivity: Better than 1.0 uv for 20 db SINAD
Adjacent channel rejection: 60db at 10Khz, 70db for 20Khz
Intermediate frequency: 1stIF=10.7 Mhz; 1nd IF=455 KHz
Audio output power: 4.5 watts max
Frequency response: 450-2500Hz
For Transmitter
Frequency coverage: 26.965 to 27.405 MHz(EU band), 26.960 to 27.400 Mhz(Poland)
Duty cycle: 5/5/90
Output power: 4watts max
Type of modulation: AM/FM
Max deviation: 2.0 Khz FM;80% AM
Frequency tolerance: better than 0.002%
Antenna Impedance: 50 Ohm
Power supply:13.8v
Weight: 1.2 kg
Reference standard
Cept PR 27 radio equipment ETS 300 135 and ETS 300 433
EIA/TIA-382-A
