China (Mainland)
Deyuan marine
various
Welded
Aluminum Alloy
ISO,CB,GB,JIS
CCS,BV,DNV,NK,ABS,GL,LR
Customerized
wooden pallet or iron pallet
10-60days according to the quantity
Aluminum Alloy Wharf Ladder:
Standard:CB3116-82, JIS F2613-1796 & ISO7061-1993
Max usage angle:30º
Usage situation: embark and disembark for personnel when various types of ships are mooring alongside a deck
*It also can be called as aluminum gangway or shore gangway.
*Normally it is with hook in one side and another side with roller.
*If the length is too long, not suitable for shipment. The ladder can be made with two parts.
*The wharf ladder also can be with the safety net.
1-Roller: Nylon
2-Ladder:Alumimum Alloy
3-Rope: Nylon
4-Hook: Aluminum Alloy or Steel
L | I | H | h |
8000 | 3200 | 350 | 170 |
10000 | 4830 | 500 | 250 |
12500 | 4830 | 550 | 250 |
15000 | 7230 | 750 | 250 |
The size in the list is just for reference. The length and the width are customerized. But the standard width is inside 600mm, outside 700mm.
