DEYUAN MARINE
marine watertight door
Hinge
Aluminum Steel SS
Plywood pallet with plastic film wrapping
15-30 days
Aluminum Marine Watertight Doors Manufacture For Ships
1.Type:Aluminum marine watertight door.
2.Material:Aluminum and steel.
3.Types:Quick closing aluminum watertight door.
Aluminum marine watertight door
China Deyuan Marine Fitting Co.,ltd is a leading supplier of marine outfitting equipment,such as marine steel doors,marine aluminum door,marine windows,marine hatch cover,marine pilot rope ladder,embarkation rope ladder,gangway ladder etc.
This product applies to aluminum door on casting walls of military and merchant ships,also applies to others
Size of doorway B*L*R | Theoretical size of door sheet B1*L1*R1 | Hole size of Casting wall B2*L2*R2 | Outline size of door frame B3*L3*R3 | Position size of hinge and handle | Quantity of handles |
500*1000*100 | 540*1040*120 | 580*1080*140 | 654*1154*177 | 300 | 4 |
500*1200*100 | 540*1240*120 | 580*1280*140 | 654*1354*177 | 400 | 5 |
500*1400*100 | 540*1440*120 | 580*1480*140 | 654*1554*177 | 500 | 5 |
600*1200*100 | 640*1240*120 | 680*1280*140 | 754*1354*177 | 400 | 5 |
600*1400*100 | 640*1440*120 | 680*1480*140 | 754*1554*177 | 500 | 5 |
650*1600*100 | 690*1640*120 | 730*1680*140 | 804*1754*177 | 600 | 5 |
Zhuhai City Deyuan Import & Export Co., Ltd
Contact: Gary
E-mail: sales9[at]deyuanmarine[dot]com
Skype:marinesales9
Tel: + 86 - 756 - 6302052
Fax: + 86 - 756 - 8305812
Mobile: + 86 - 13798955750
Web: http://www.deyuanmarine.com
