CCS, BV Approved Marine Azimuth Thruster

Availability:
  • DEYUAN





1 Drive shaft assemblly
  with bevel gear pinion
2 Mechanical feed back
3 Oil transmission pipe
4 Bevel gear wheel
5 Propeller shaft assembly
6 Crank pin ring
7 Crosshead with sliding shoes
8 Actuating piston
9 Blade sealing



Propeller diameter Power Frequency Input power Zero pitch torque Moment of inertia Weight kg
mm kw max Hz RPm Nm max kgm2 transverse thrust unit Motor and starter
1100 -320 50 1450 160 1.2 1300 850
-380 60 1750 220
1300 -445 50 1450 340 1.9 2500 1300
-480 60 1750 470
1650 -590 50 1450 340 4.5 3700 2300
-800 60 1750 500
2000 -880 50 1450 840 11.3 6250 3300
-1200 60 1190 570
2400 -1580 50 980 2270 28.8 12500 4500
-1720 60 1190 3050
2800 -2240 50 980 3935 65 20500 5000
-2010 60 880 3300
3300 -3500 50 590 5600 358 31000 6000
-3500 60 590 5600




* * * does not include the input shaft for motor and starter * * * input 100% speed when the shaft torque size   (mm)Dimensions





Propeller diameter

a c d e g h i t k l m n
1100 1120 1330 175 340 505 70 50 15 30 1045 1283 842
1300 1328 1538 190 345 615 80 50 15 30 1190 1470 933
1650 1680 1910 260 390 730 90 50 15 50 1390 1797 1145
2000 2026 2270 340 420 900 110 50 22 50 1680 2195 1395
2400 2430 2682 310 500 1080 140 50 26 50 1990 2532 1647
2800 2836 3206 395 620 1210 150 60 35 60 2280 2990 1930
3300 3340 3710 465 730 1425 175 60 35 70 2685 3530 2280
