DIN Type Ship Roller Fairlead with good price for hot sale

DIN Type Ship Roller Fairlead with good price for hot sale

DIN Type Roller Fairlead with good price for hot sale

1.Roller Fairlead; Swivel Fairlead;
2.Certificate of GL,DNV,CCS,ABS,BV;
3.Material: Steel;
4.Design by customers' requirement.

DIN type roller fairlead



Four Roller Fairlead:

1.Roller Fairlead; Fairlead
2.Certificate of GL,DNV,CCS,ABS,BV
3.Material: Steel
4.Design and manufacture according customers' requirements

Rated towing pull	Rope (mm)	Wre size (mm)	A (mm)	B	C	D	E	F	G	weight
20KN	-12	12	180	100	650	80	446	170	10	75kg
30KN	-16	16	230	130	800	100	546	210	10	130kg
50KN	-20	20	250	130	900	120	626	250	15	220kg
80KN	-24	24	280	160	1000	140	716	288	20	320kg
120KN	-32	32	300	160	1200	180	836	366	25	580kg
200KN	-40	40	320	180	1350	245	1030	500	35	1100kg
320KN	-48	40	400	250	1700	300	1236	610	45	2210kg
