Electric Operated Fire Monitor (SS80EL)

Electric Operated Fire Monitor (SS80EL)



Electric Operated Fire Monitor (SS80EL)

1.Effective capacity:   4000L/min.

2.The max pressure:    16bar.

3.Inlet:   Flange DN80 PN16 .



4.Outlet:   Screw thread.

5.Optional inlet flange: DN100 PN16/ ANSI3''

Electric Operated Fire Monitor (SS80EL)

SS80EL Standard Design Parameters      SS80WEL/F; SS80EL/F

China Deyuan Marine Fitting Co.,ltd is leading supplier of FIFI system,Fire fighting system,

marine fire pump,foam fire monitor,fire monitor,electric fire monitor,CO2 Fire-extinguishing system,

fire extinguishing system,Pls contact us for more specific details.



Descriptions:    Produced on requirement



Effective capacity:   4000L/min



The max pressure:    16bar



Inlet:   Flange DN80 PN16



Outlet:   Screw thread



Optional inlet flange: DN100 PN16/ ANSI3''



Rotation range:



Horizontal:  340°



Vertical:   +85°~ -75°



Weight:  ~75Kg



Materials:



Body:  Stainless Steel/Carbon Steel/Anti-corrosion aluminum alloy



Sealing:  NBR



Pipe:   Hard aluminum alloy



Flange:  Stainless Steel/Carbon Steel/Anti-corrosion aluminum alloy



Painting:   Red RAL3000

The monitor can be arrested in any horizontal or vertical position
