Guangdong, China (Mainland)
DEYUAN MARINE
PSKD80
stainless steel &carbon steel& aluminum alloy
Red
18000L/MIN
manual operation
water &AFFF
wooden case
10-30days
1)Type of fire monitor :double pipe/double barrel fire monitor/fire fighting monitor
2)Fire Monitor Capacity:18000L/MIN
3)Fire Monitor Model:SS150&PSKD150
4)Fire Monitor Material:stainless steel/carbon steel/Anti-corrosion aluminum alloy
5)Medium:Water &AFFF
*Effective capacity: 18000L/min
*The max pressure: 16bar
*Inlet: Flange DN150 PN16
*Outlet: Square flange
Optional inlet flange: DN200/ANSI6''
*Materials:
Body: Stainless Steel/Carbon steel/Anti-corrosion aluminum alloy
Sealing: NBR
Pipe: Hard aluminum alloy
Flange: Stainless Steel/Carbon steel/Anti-corrosion aluminum alloy
Painting: Red RAL3000
The monitor can be arrested in any horizontal or vertical position
Rotation range:
Horizontal: 360° infinite
Vertical: +75°~ -45°
Weight: ~165kg
Zhuhai City Deyuan Import & Export Co., Ltd
Contact: Tina Zhu
E-mail: sales5[at]deyuanmarine[dot]com
Skype: marinesales5
Tel: + 86 - 756 - 6302052
Fax: + 86 - 756 - 8305812
Mobile: + 86 - 13286053269
Web: http://www.deyuanmarine.com
