Fire Foam Monitor (SS300EL)

1.Effective capacity:   60000L/min.

2.The max pressure:   16bar.

3.Inlet:   Flange DN300 PN16.

4.Outlet:   Flange connection



SS300EL Standard Design Parameters      SS300EL/F



China Deyuan Marine Fitting Co.,ltd is leading supplier of FIFI system,Fire fighting system,marine fire pump,foam fire monitor,fire monitor,electric fire monitor,CO2 Fire-extinguishing system,fire extinguishing system,Pls contact us for more specific details.



Descriptions:    Produced on requirement



Effective capacity:   60000L/min



The max pressure:   16bar



Inlet:   Flange DN300 PN16



Outlet:   Flange connection



Optional inlet flange:  ANSI12''



Rotation range:



Horizontal:  340°



Vertical:   +75°~ -45°



Weight:  ~800Kg



Materials:



Body:  Stainless Steel/Anti-corrosion aluminum alloy/Copper alloy



Sealing:  NBR



Pipe:   Hard aluminum alloy/Stainless steel



Flange:  Stainless Steel/Copper alloy



Painting:   Red RAL3000

The monitor can be arrested in any horizontal or vertical position
