Fire Monitor (SS250EL)

Availability:
Inquire Add to Basket

  • Deyuan Marine

Fire Monitor (SS250EL)



Fire Monitor (SS250EL)

1.Effective capacity:   32000L/min.

2.The max pressure:    16bar.

3.Inlet:   Flange DN250 PN16.

4.Outlet:   Flange connection

Fire Monitor (SS250EL)

SS250EL Standard Design Parameters    SS250EL/F

China Deyuan Marine Fitting Co.,ltd is leading supplier of FIFI system,Fire fighting system,

marine fire pump,foam fire monitor,fire monitor,electric fire monitor,CO2 Fire-extinguishing system,

fire extinguishing system,Pls contact us for more specific details.

Descriptions:    Produced on requirement

Effective capacity:   32000L/min

The max pressure:    16bar

Inlet:   Flange DN250 PN16

Outlet:   Flange connection

Optional inlet : Flange DN300 / ANSI10''

Rotation range:

Horizontal:  340°

Vertical:   +75°~ -45°

Weight:  ~550Kg

Materials:

Body:  Stainless Steel/Anti-corrosion aluminum alloy/Copper alloy

Sealing:  NBR

Pipe:   Hard aluminum alloy

Flange:  Stainless Steel/Anti-corrosion aluminum alloy/Copper alloy

Painting:   Red RAL3000

The monitor can be arrested in any horizontal or vertical position
