Fire Monitor With Adjustment By Electric Motor With High Quality

Fire Monitor With Adjustment By Electric Motor With High Quality

1.Effective capacity:   2400L/min.

2.The max pressure:  16bar.

3.Inlet:   Flange DN65 PN16 .

4.Outlet:   2'' screw thread

Fire Monitor with Adjustment by Electric Motor

SS65EL Standard Design Parameters      SS65FEL/F

China Deyuan Marine Fitting Co.,ltd is leading supplier of FIFI system,Fire fighting system,marine fire pump,foam fire monitor,fire monitor,electric fire monitor,CO2 Fire-extinguishing system,fire extinguishing system,Pls contact us for more specific details.

Descriptions:    Produced on requirement

Effective capacity:   2400L/min

The max pressure:  16bar

Inlet:   Flange DN65 PN16

Outlet:   2'' screw thread

Optional inlet flange: DN80 PN16 / ANSI2½''/ANSI3''

Rotation range:

Horizontal:  340°

Vertical:   +90°~ -75°

Weight:  ~60Kg

Materials:

Body:  Stainless Steel/Carbon steel/Anti-corrosion aluminum alloy

Sealing:  NBR

Pipe:   Hard aluminum alloy

Flange:  Stainless Steel/Carbon steel/Anti-corrosion aluminum alloy

Painting:   Red RAL3000

The monitor can be arrested in any horizontal or vertical position
