Guangdong, China (Mainland)
DEYUAN MARINE
PSKD80
Stainless steel
red
4000L/MIN
manual operation
water &AFFF
wooden case
10-30days
1)Type of fire monitor available: manual fire monitor/water fire monitor
2)Fire Monitor Capacity:4000L/MIN
3)Fire Monitor Model:PSKD80
4)Fire Monitor Material:stainless steel/carbon steel/Anti-corrosion aluminum alloy
5)Medium:Water &AFFF
*Effective capacity: 4000L/min
*The max pressure: 16bar
*Inlet: Flange DN100 PN16
*Outlet: Square flange
Optional inlet flange: DN150/ANSI4''
*Materials:
Body: Stainless Steel/Carbon steel/Anti-corrosion aluminum alloy
Sealing: NBR
Pipe: Hard aluminum alloy
Flange: Stainless Steel/Carbon steel/Anti-corrosion aluminum alloy
Painting: Red RAL3000
The monitor can be arrested in any horizontal or vertical position
Rotation range:
Horizontal: 360° infinite
Vertical: +85°~ -75°
Weight: ~165kg
