Marin advantages:
1.Electro-hydraulic control.
2.Compact design.
3.Suitable for normal rudder blades.
4.Pumps with variable displacement or constant delivery.
5.One-piece tiller for standard or keyless fit of rudder stock.
6.Pump units mounted on and completely piped with the cylinders.
Fork-type hydraulic steering gear(single rudder)
1)Suitable for:
Containers, tankers, ferries, General cargo ships, passage ships
Dredgers and any other vessels that need more steering torque.
(2)Main Tech:
Max working torque: 15 KN.M — 250 KN.M
Max. mech. rudder angle: ± 45 degree
Time of rudder movement: ≤28 S
Rudder stock Diameter: 300mm — 900 mm
Working pressure: 13 Mpa — 20 Mpa
Design pressure: 16 Mpa — 24 Mpa
(3)Scope of delivery:
Marine steering gear with hydraulic cylinders
Electro-Hydraulic power station with oil pumps
Oil tanks
Start motors
On requests, the full range of parts will be delivered.
