Marine Fork-type hydraulic steering gear single rudder

Availability:
  • Deyuan Marine

Fork-type hydraulic steering gear single rudder

Marin advantages:

1.Electro-hydraulic control.

2.Compact design.

3.Suitable for normal rudder blades.

4.Pumps with variable displacement or constant delivery.

5.One-piece tiller for standard or keyless fit of rudder stock.

6.pump units mounted on and completely piped with the cylinders.



Fork-type hydraulic steering gear single rudder

(1)Suitable for:

Containers, tankers, ferries, General cargo ships, passage ships

Dredgers and any other vessels that need more steering torque



(2)Main Tech:

Max working torque:              15 KN.M — 250 KN.M

Max. mech. rudder angle:       ± 45 degree

Time of rudder movement:     ≤28 S

Rudder stock Diameter:          300mm — 900 mm

Working pressure:                  13 Mpa — 20 Mpa



(3)Design pressure:                    16 Mpa — 24 Mpa

Marine steering gear with hydraulic cylinders

Electro-Hydraulic power station with oil pumps

Oil tanks

Start motors

On requests, the full range of  parts will be delivered.
