Hot Sales Marine Fire Monitor With 1200M3/H Capacity For Ship

Hot Sales Marine Fire Monitor With 1200M3/H Capacity For Ship



1)Type of fire monitor :Electric  double type fire monitor

2)Fire Monitor Capacity:32000L/MIN

3)Fire Monitor Model:SS250EL

4)Fire Monitor Material:stainless steel/carbon steel/Anti-corrosion aluminum alloy

5)Medium:Water &AFFF

6) Certificate:CCS,ABS,DNV,RINA,LR etc





*Fire Monitor capacity: 32000L/min

*fire monitor  max pressure:  16bar

*Inlet:   Flange DN250 PN16

*Outlet: flange connection

Optional inlet flange: DN300 / ANSI10''

Rotation range:

Horizontal:  340°

Vertical:   +75°~ -45°

Weight:  ~550Kg

Materials:

Body:  Stainless Steel/Carbon steel/Anti-corrosion aluminum alloy

Sealing:  NBR

Pipe:   Hard aluminum alloy

Flange:  Stainless Steel/Carbon steel/Anti-corrosion aluminum alloy

Painting:   Red RAL3000

The monitor can be arrested in any horizontal or vertical position
