Marine Aluminum Quick Acting Watertight Door with Single Lever

Inquire Add to Basket

  • China (Mainland)

  • Deyuan marine

  • various

  • Hinge

  • Aluminum

  • GB/T3477-96 &CB/T454-97

  • Customerized

  • Left or right outwards

  • wooden pallet or iron pallet

  • 20-60days according to the quantity

Specifications


Marine Aluminum quick acting Watertight Door
1)Lighter weight
2)Good quality with hose test
3)Quick opening & closing



Marine Aluminum Quick Acting Watertight Door

Standard: CB3477-96 &CB/T454-97 for reference.



Type:

JA-Aluminum weathertight door

JB-Aluminum weathertight door with round window

JC-Aluminum weathertight door with round window & guard bar

JD-Aluminum weathertight door with square window

JE-Aluminum weathertight door with round window & deadlight



Main Material:

Door Leaf-Aluminum

Door Frame-Aluminum(Bolted installment) or Steel (Welded installment)

Lever-Carbon Steel or Stainless Steel



Main Size List(mm):

Clear Size Cut Out Size Door leaf Size Door Frame
WXh W1Xh1 R W2Xh2 t Spec Thickness
500x1000 560x1060 130 555x1055 4,6 75x50 6,8
600x1200 660x1260 655x1255
600x1400 660x1460 655x1455
750x1400 810x1460 805x1455
900x1400 960x1460 955x1455
600x1600 660x1660 655x1655
750x1600 810x1660 805x1655
900x1600 960x1660 955x1655



4
