Marine Fire Monitor Electric Control Water Monitor

Marine Fire Monitor Electric Control Water Monitor

MarineFire Monitor Electric Control water monitor





1.Effective capacity:   2000L/min; 2400L/min.

2.The max pressure:    16bar.

3.Inlet:   Flange DN50 PN16; DN65 PN16.

4.Outlet:   Screw thread.

5.Optional inlet Flange: DN80 PN16/ANSI2''/ANSI½''.



SS65FHL Fire Monitor For FiFi System



Descriptions:    Produced on requirement

Effective capacity:   2000L/min; 2400L/min

The max pressure:    16bar

Inlet:   Flange DN50 PN16; DN65 PN16

Outlet:   Screw thread

Optional inlet Flange: DN80 PN16/ANSI2''/ANSI½''

Rotation range:

Horizontal:  360° infinite

Vertical:   +85°~ -75°

Weight:  ~16Kg

Materials:

Body:  Stainless Steel/Carbon steel/Anti-corrosion aluminum alloy

Sealing:  NBR

Pipe:   Hard aluminum alloy

Nozzle: Copper alloy / Aluminum alloy

Flange:   Stainless Steel/Carbon steel/Anti-corrosion aluminum alloy

Painting:   Red RAL3000

The monitor can be arrested in any horizontal or vertical position
