Marine Fire monitor for fire fighting (ss200EL)

Inquire Add to Basket

  • Guangdong, China (Mainland)

  • DEYUAN MARINE

  • Marine Fire monitor

  • 16 bar

  • 26000L/min

  • Square flange.

  • Flange DN200 PN16

  • ~750Kg

  • wooden case

  • 10-30days

1.Effective capacity:   26000L/min.

2.The max pressure:  16bar.

3.Inlet:   Flange DN200 PN16 .

4.Outlet:   Square flange.

Fire monitor for fire fighting (ss200EL)

SS200EL Standard Design Parameters      SS200EL/F; SS200WEL/F

Descriptions:    Produced on requirement

Effective capacity:   26000L/min

The max pressure:  16bar

Inlet:   Flange DN200 PN16

Outlet:   Square flange

Optional inlet : DN250 / ANSI8''

Rotation range:

Horizontal:  340°

Vertical:   +75°~ -45°

Weight:  ~750Kg

Materials:

Body:  Anti-corrosion / Aluminum alloy

Sealing:  NBR

Pipe:   Hard aluminum alloy/ Aluminum alloy

Flange:  Anti-corrosion / Aluminum alloy

Painting:   Red RAL3000

The monitor can be arrested in any horizontal or vertical position
