Marine Foam Fire Monitor,Remote Control Fire Monitor (SS300EL)
Fire Foam Monitor (SS300EL)
Descriptions: Produced on requirement
Effective capacity: 60000L/min
The max pressure: 16bar
Inlet: Flange DN300 PN16
Outlet: Flange connection
Optional inlet flange: ANSI12''
Rotation range:
Horizontal: 340°
Vertical: +75°~ -45°
Weight: ~800Kg
Materials:
Body: Stainless Steel/Anti-corrosion aluminum alloy/Copper alloy
Sealing: NBR
Pipe: Hard aluminum alloy/Stainless steel
Flange: Stainless Steel/Copper alloy
Painting: Red RAL3000
The monitor can be arrested in any horizontal or vertical position
Marine Foam Fire Monitor,Remote Control Fire Monitor (SS300EL)
Fire Foam Monitor (SS300EL)
Descriptions: Produced on requirement
Effective capacity: 60000L/min
The max pressure: 16bar
Inlet: Flange DN300 PN16
Outlet: Flange connection
Optional inlet flange: ANSI12''
Rotation range:
Horizontal: 340°
Vertical: +75°~ -45°
Weight: ~800Kg
Materials:
Body: Stainless Steel/Anti-corrosion aluminum alloy/Copper alloy
Sealing: NBR
Pipe: Hard aluminum alloy/Stainless steel
Flange: Stainless Steel/Copper alloy
Painting: Red RAL3000
The monitor can be arrested in any horizontal or vertical position
