Marine Mooring Fairlead Anchor Roller
Features:
1.Standrad:GB10105-88.
2.Material: cast iron, cast steel.
3.Open roller for deck, tapper pin at the centre.
4.Marine mooring equipment, marine fairlead roller.
Marine cast steel fairlead roller
Open roller for deck, tapper pin at the centre
Marine mooring equipment, marine fairlead roller
Size | D | D1 | H | S |
150 | 150 | 240 | 154 | 5 |
200 | 200 | 310 | 186 | 5 |
250 | 250 | 380 | 230 | 6 |
300 | 300 | 440 | 255 | 7 |
350 | 350 | 500 | 271 | 7 |
400 | 400 | 560 | 307 | 7 |
450 | 450 | 630 | 316 | 7 |
JISF,DIN and GB standards, standard:CB*58-83 |
