China (Mainland)
Deyuan Marine
various
Hinge
Steel
GB/T3477-96
Customerized
Left or right outwards
wooden pallet or iron pallet
20-60days according to the quantity
Marine Steel Quick Acting Watertight Door
Standard:GB/T3477-1996 for reference
The steel weathertight door must pass the hose test with nozzle diameter 12.5mm and the water pressure 0.25Mpa.
Type:
JA-Steel weathertight door
JB-Steel weathertight door with round window
JC-Steel weathertight door with round window & guard bar
JD-Steel weathertight door with square window
JE-Steel weathertight door with round window & deadlight
Main Material:
Door Leaf-Steel (Q235A)
Door Frame-Steel (Q235A)
Lever-Carbon Steel or Stainless Steel
Clear Size | Cut Out Size | Door leaf Size | Door Frame | |||
WXh | W1Xh1 | R | W2Xh2 | t | Spec | Thickness |
500x1000 | 560x1060 | 130 | 555x1055 | 6,8 | 75x50 | 6,8 |
600x1200 | 660x1260 | 655x1255 | ||||
600x1400 | 660x1460 | 655x1455 | ||||
750x1400 | 810x1460 | 805x1455 | ||||
900x1400 | 960x1460 | 955x1455 | ||||
600x1600 | 660x1660 | 655x1655 | ||||
750x1600 | 810x1660 | 805x1655 | ||||
900x1600 | 960x1660 | 955x1655 |
