Marine Single Lever Steel quick acting Weathertight Door with Round Window

  • China (Mainland)

  • Deyuan Marine

  • various

  • welded, hinged

  • Steel

  • GB/T3477-96

  • Customerized

  • Left or right outwards

  • 6/8mm

  • wooden pallet or iron pallet

  • 20-60days according to the quantity



Marine Single Lever Steel Quick Acting Weathertight Door with Round Window

Standard:GB/T3477-1996 for reference

The steel weathertight door must pass the hose test with nozzle diameter 12.5mm and the water pressure 0.25Mpa.





Type:

JA-Steel weathertight door

JB-Steel weathertight door with round window

JC-Steel weathertight door with round window & guard bar

JD-Steel weathertight door with square window

JE-Steel weathertight door with round window & deadlight





Main Material:

Door Leaf-Steel (Q235A)

Door Frame-Steel (Q235A)

Lever-Carbon Steel or Stainless Steel





Main Size List(mm):

Clear Size Cut Out Size Door leaf Size Door Frame
WXh W1Xh1 R W2Xh2 t Spec Thickness
500x1000 560x1060 130 555x1055 6,8 75x50 6,8
600x1200 660x1260 655x1255
600x1400 660x1460 655x1455
750x1400 810x1460 805x1455
900x1400 960x1460 955x1455
600x1600 660x1660 655x1655
750x1600 810x1660 805x1655
900x1600 960x1660 955x1655

 7
