Small type marine vertical oil fired boiler
1.little cubage, simple and firm structure, small installed area.
2.Suitable for ships with steam capacity lower than 6.0t/h.
3.Applicable for cargo ship,small oil tanker,container ship,engineering ship,RO/RO etc.
Small type marine vertical oil fired boiler fired boiler is running automatically, this is right for different ship companies, who want ship cabin with no person operating. When the automatic controlling system is wrong and the cool-boiler is started, it can be controlled by hand. The alarm signal-output set connected outside is installed in the boiler control pocket, the same as remote-control emergency cut connection tip.
There is a manhole in the nominal part in this series boiler, convenient for the inspection and maintaining of the boiler's water surface. There are many hand hole underside the boiler, not only for the inside clearing, but also for the connection with exhaust-gas economizer.
Vaporized Quantum | Working Pressure | Overall Dimension( mm ) | Net Weight of Boiler (Kg) | Water Capacity | ||
A | B | ΦC | ||||
500 | 0.7 | 3550 | 3100 | 1250 | 2600 | 1.2 |
700 | 0.7 | 3750 | 3300 | 1250 | 2900 | 1.3 |
1000 | 0.7 | 3870 | 3370 | 1450 | 3400 | 1.9 |
1200 | 0.7 | 3910 | 3410 | 1500 | 3900 | 2.1 |
1500 | 0.7 | 4130 | 3630 | 1650 | 4500 | 2.7 |
2000 | 0.7 | 4410 | 3910 | 1750 | 5400 | 3.0 |
2500 | 0.7 | 4380 | 3880 | 1950 | 6900 | 3.8 |
3000 | 0.7 | 4680 | 4080 | 2050 | 7700 | 4.9 |
4500 | 0.7 | 5240 | 4590 | 2350 | 11400 | 6.8 |
6000 | 0.7 | 6180 | 5480 | 2450 | 14000 | 8.4 |
