0.5T/H Factory Direct Gas Fired Marine Vertical Steam Boiler For Sale

Availability:

0.5T/H Factory Direct Gas Fired Marine Vertical Steam Boiler For Sale

0.5T/H Factory Direct Gas Fired Marine Vertical Steam Boiler For Sale

1.Type: HOB marine boiler

2.Capacity:6.0t/h~20t/h.

3.Takes use of pin-tube in its convective heat-absorbing surface.

HOB marine boiler

The OBL oil-fired assisted boiler takes use of pin tube in its convective heat-absorbing surface and installs the membrane water-cooled wall as its furnace wall, its steam capacity is 6.0t/h~20t/h. Such series boiler can be used a lot on oil tanker and chemical material ship etc. The steam output is used for the running of the steam turbine and the pump for goods loading and unloading, for heating the goods cabin ,for the places where more steam is needed.



Such series boiler uses pin-tube as the heat-transferring element, compared with other boilers, its heat-transferring elements are reduced a lot, and its cubage is smaller and more intense so that much cabin room area is saved. At the same time, this series boiler has a simple structure , its heat-transferring tubes are arranged parallevelly, as a result, the water circulates well here. The membrane water-cooled wall, whose quality is as good as the host boiler on the ship or the boiler in power plant, in the furnace is extremely firm. While the furnace is sealed off, it is suitable for burning with pressure.



Steam Output
(kg/h)

Working Pressure
(MPa)

A
(mm)

Ø D
(mm)

H
(mm)

Water Capacity
(m3 )

Net Weight of
Boiler (kg)

6500

1.0

5200

2700

6050

6.7

12650

8000

1.0

5800

2700

6600

7.0

13900

10000

1.0

6400

2700

7200

7.0

15200

12000

1.0

6400

3160

7300

10.5

18800

16000

1.6

7100

3360

7980

13.2

24900

20000

1.6

7200

3560

8100

13.5

28500

25000

1.6

7680

3860

8650

14.2

35000

30000

1.6

8280

3860

9250

14.5

37000

35000

1.6

8400

4160

9650

17.8

42800
