Marine mooring single roller fairlead with cleat CB436-2000 type A

Specifications

Roller Fairlead:
1.Excellent quality.
2.Competitive price .
3.Durable, long lifetime.
4.Certificate: CCS BV ABS.

Roller fairlead:

Marine mooring single roller fairlead with cleat CB436-2000 type A:

Features:

1.Excellent quality.
2.Competitive price .
3.Durable, long lifetime.
4.Certificate: CCS BV ABS.

Used for guiding ropes in ship mooring and will not breakdown.
Provide CCS , BV , LR , BV etc Certificate

Customized service is available, Advanced equipment ,Strong consciousness in controlling quality

Material: Cast iron

Machining facilities :CNC center, CNC lathes, ultrasonic wave cleaning, etc

Good wear and corrosion resistance

According standard to produce.

Drawing:

CB436-2000 Cleat fairlead with single roller type A
Product No.	Nominal	Steel rope GB1102 Breaking Load 1520N/mm2			Dimension													Roller weight KG		Base weight kg H1=1000
Product No.	Size(mm)	*624**	*630**	*637**	D1	D2	D3	D4	D5	L	H	H1	H2	H3	S	t	t1	Cast iron	Cast steel	Base weight kg H1=1000
CBRA-001	150	17	17.5	15	240	270	90	71	60	245	211	The base height is as per your request	40	75	3	12	8	32.1	33.8	129
CBRA-002	200	22.5	21.5	19.5	310	340	115	95	80	285	251		50	85	3	14	10	64.6	68	178
CBRA-003	250	24	26	24	380	410	140	107	90	323	298		60	100	4	14	10	108	114	207
CBRA-004	300	30	32.5	28	440	470	160	127	110	355	321		60	100	4	16	14	159	168	265
CBRA-005	350	37.5	39	34.5	500	530	180	144	125	390	346		65	100	4	18	14	235	248	332
CBRA-006	400	41	39	39	560	590	200	161	140	420	371		70	100	5	20	16	336	355	401
CB436-2000 A type:Adopt CB 58-83 fairlead roller
