SS125WHR/F Fire Monitor

  • Deyuan Marine

Fire Foam Monitor (SS125)


Fire Foam Monitor (SS125)

1.Effective capacity:   9000L/min.

2.The max pressure:    16bar.

3.Inlet:   Flange DN150 PN16.

4.Outlet:   Flange connection.

5.Optional inlet flange: DN150/ANSI6

Fire Foam Monitor (SS125)

SS125 Standard Design Parameters     SS125WHR/F

China Deyuan Marine Fitting Co.,ltd is leading supplier of FIFI system,Fire fighting system,

marine fire pump,foam fire monitor,fire monitor,electric fire monitor,CO2 Fire-extinguishing system,

fire extinguishing system,Pls contact us for more specific details.

Descriptions:    Produced on requirement

Outlet:   Flange connection

Optional inlet flange: DN150/ANSI6

Rotation range:

Horizontal:  360° infinite

Vertical:   +75°~ -45°

Weight:  ~75Kg


Body:  Anti-corrosion aluminum alloy/Copper alloy

Sealing:  NBR

Pipe:   Hard aluminum alloy

Flange:   Anti-corrosion aluminum alloy/Copper alloy

Painting:   Red RAL3000

The monitor can be arrested in any horizontal or vertical position
