Fire Foam Monitor (SS125)
SS125
9000L/min
16bar
Flange DN150 PN16
Flange connection
DN150/ANSI6
360° infinite
+75°~ -45°
~75Kg
Anti-corrosion aluminum alloy/Copper alloy
Standard export packing
Within 30 days
Fire Foam Monitor (SS125)
Fire Foam Monitor (SS125)
1.Effective capacity: 9000L/min.
2.The max pressure: 16bar.
3.Inlet: Flange DN150 PN16.
4.Outlet: Flange connection.
5.Optional inlet flange: DN150/ANSI6
Fire Foam Monitor (SS125)
SS125 Standard Design Parameters SS125WHR/F
China Deyuan Marine Fitting Co.,ltd is leading supplier of FIFI system,Fire fighting system,marine fire pump,foam fire monitor,fire monitor,electric fire monitor,CO2 Fire-extinguishing system,fire extinguishing system,Pls contact us for more specific details.
Descriptions: Produced on requirement
Outlet: Flange connection
Optional inlet flange: DN150/ANSI6
Rotation range:
Horizontal: 360° infinite
Vertical: +75°~ -45°
Weight: ~75Kg
Materials:
Body: Anti-corrosion aluminum alloy/Copper alloy
Sealing: NBR
Pipe: Hard aluminum alloy
Flange: Anti-corrosion aluminum alloy/Copper alloy
Painting: Red RAL3000
The monitor can be arrested in any horizontal or vertical position
