Stainless steel electric fire monitor double pipe type

Inquire Add to Basket

  • Jiangsu, China (Mainland)

  • DEYUAN MARINE

  • SS150

  • Stainless steel

  • 18000L/min

  • 16bar

  • Flange DN150 PN16

  • Flange connection

  • DN200 / ANSI6''

  • CCS

  • Packaging: Wooden case

  • 10-30 days

                                                                                        Electric fire monitor



1.Effective capacity:   18000L/min.

2.The max pressure:    16bar.

3.Inlet:   Flange DN150 PN16.

4.Outlet:   Flange connection.

5.Optional inlet : DN200 / ANSI6''



Double pipe fire monitor(SS150)

SS150 Double Pipe Monitor / stainless steel electric fire monitor

Standard Design Parameters      (SS150DHR/F)

Descriptions:    Produced on requirement

Effective capacity:   18000L/min

The max pressure:    16bar

Inlet:   Flange DN150 PN16

Outlet:   Flange connection

Optional inlet : DN200 / ANSI6''

Rotation range:

Horizontal:  360° infinite

Vertical:   +75°~ -45°

Weight:  ~165Kg

Materials:

Body:  Stainless Steel/Anti-corrosion aluminum alloy/Copper alloy

Sealing:  NBR

Pipe:   Hard aluminum alloy

Flange:  Stainless Steel/Anti-corrosion aluminum alloy/Copper alloy

Painting:   Red RAL3000

The monitor can be arrested in any horizontal or vertical position
